1.Product Introduction
The Kingkangda High-Speed Roller-Disc Raising Machine delivers uniform and fine raising effects for wool and synthetic fancy yarns. Designed with automatic stop functions, it ensures stable and safe production. With Kingkangda’s trusted technology, you can enhance both fabric quality and production efficiency.

2. Product Description
The Kingkangda High-Speed Roller-Disc Raising Machine adopts advanced servo-driven disc rollers, providing precise speed and tension control for consistent fiber raising quality. The unique roller-disc combination offers optimal friction and contact, effectively lifting fiber ends without damaging their structure, resulting in fabrics with superior softness, fullness, and comfort.

Equipped with automatic yarn break detection and full cone stop, the machine minimizes downtime and reduces material waste. Its robust frame and ergonomic layout allow operators to inspect and maintain the equipment conveniently.

With a yarn count range of 2–15Nm, the machine meets diverse production requirements for various wool and synthetic fancy yarns, delivering stable quality and efficiency for medium-to-low count fancy yarn production.

3. Technical Features

Servo Motor Driven Disc Rollers
Independent high-precision servo motors drive the disc rollers and take-up unit, ensuring smooth operation, stable raising quality, and adaptability to various yarn types.

Optimized Roller-Disc Contact for Effective Raising
The roller-disc design provides greater frictional efficiency, effectively raising fibers while protecting their structure, especially suitable for medium and fine fancy yarns.

Automatic Yarn Break & Full Cone Stop
Advanced sensors monitor yarn tension, triggering immediate stop when yarn breaks or cones are full, reducing waste and preventing equipment damage.

Adjustable Yarn Tension
Operators can dynamically adjust yarn tension to ensure uniform fiber raising and consistent yarn quality.

1. The main technical parameters
